MAP sensor ID?


Post new topic   Reply to topic    EFI University Forum Index -> Other
View previous topic :: View next topic
Author Message
C. Ludwig



Joined: 29 Sep 2006
Posts: 354

PostPosted: Mon Sep 22, 2014 6:25 am    Post subject: MAP sensor ID? Reply with quote

Siemens sensor which is OE on a Chinese 1100cc Cherry buggy engine. Need pin out, MAP scale, and IAT calibration, if possible. Thanks!




_________________
Haltech, Syvecs, AEM, Apexi PFC Sales, Installation, Tuning
Custom Harness Solutions
www.ludwigmotorsports.com
Back to top
View user's profile Send private message
C. Ludwig



Joined: 29 Sep 2006
Posts: 354

PostPosted: Mon Sep 22, 2014 6:02 pm    Post subject: Reply with quote

Found it.

1.2 bar max.

1 - MAP
2 - 5V
3 - IAT
4 - GND
